DC2677A

High Voltage, 18-Bit, 8-Channel Data Acquisition Reference Design.

https://media.githubusercontent.com/media/analogdevicesinc/documentation/main/docs/solutions/reference-designs/dc2677a/images/dc2677a_chip.png

Overview

Demonstration circuit 2677A (DC2677A) is a reference design for robust industrial data acquisition applications for the LTC2358-18. The device supports high voltage measurements with a large input common range and incorporates input protection that allows up to 400V of continuous input protection.

The design features an ADA4522-2 dual zero-drift operational amplifier and LT6658 dual-output, high current reference for sensor excitation. The digital interface uses an HSMC (high-speed mezzanine connector), compatible with the Altera Cyclone V SoCkit and other Altera FPGA evaluation boards supporting 3.3V CMOS I/O.

Supported Devices

Supported Carriers

DC2677A

Cyclone V SoC Development Kit

LTC2358-18

Features:

  • 18-bit, 8-channel SAR ADC with SoftSpan programmable input ranges

  • Up to 400V continuous input overvoltage protection

  • Dual zero-drift amplifier (ADA4522-2) for low offset and low drift

  • Dual-output high current reference (LT6658) for sensor excitation

  • HSMC interface compatible with Altera Cyclone V SoCkit and other Altera FPGA boards supporting 3.3V CMOS I/O

Applications:

  • High voltage industrial data acquisition

  • Process control and monitoring

  • Sensor excitation and signal conditioning

  • High accuracy measurement systems

https://media.githubusercontent.com/media/analogdevicesinc/documentation/main/docs/solutions/reference-designs/dc2677a/images/dc2677a.png

Recommendations

People who follow the flow that is outlined, have a much better experience with things. However, like many things, documentation is never as complete as it should be. If you have any questions, feel free to ask on our EngineerZone forums, but before that, please make sure you read our documentation thoroughly.

To better understand the LTC2358-18, we recommend using the DC2677A evaluation board.
