EVAL-AD9656

Quad, 16-Bit, 125 MSPS, Serial Output ADC with JESD204B Interface.

Overview

The EVAL-AD9656, is a FMC evaluation board for the AD9656, a quad, 16-bit, 125 MSPS serial output analog-to-digital converter (ADC) with JESD204B interface. The AD9656 is designed for low power, small size, and ease of use, and features a multistage, differential pipelined architecture with integrated output error correction logic.

Features:

• SPI interface for setup and control

• External, on-board 125 MHz crystal oscillator

• On-board LDO regulator, needing a single external 6V, 2A dc supply

• ADC VREF configurable for ADC-internal reference, on-board reference, off-board reference

• JESD204B serial output interface

• VisualAnalog and SPIController software interfaces

Applications:

• Communications

• Instrumentation and measurement

• Medical imaging

• Phased array radar

Recommendations

People who follow the flow that is outlined, have a much better experience with things. However, like many things, documentation is never as complete as it should be. If you have any questions, check the Help and Support section at the bottom of the page.

To better understand the AD9656, we recommend to use the EVAL-AD9656 evaluation board.

Table of contents

1. Using the evaluation board:

   1. Prerequisites — what you need to get started

   2. Quick start guides:

      1. Using the ZCU102 with no-OS

      2. Using the HSC-ADC-EVALEZ with VisualAnalog

   3. User guide — hardware and board details

2. Design with the AD9656

   1. AD9656 product page

   2. HDL reference design which you must use in your FPGA.

3. Help and Support

ADI articles

About JESD standard:

1. JESD204B Survival Guide

Helpful documents

• AD9656 data sheet

• AN-905 Application Note, VisualAnalog Converter Evaluation Tool Version 1.0 User Manual

• AN-878 Application Note, High Speed ADC SPI Control Software

• AN-877 Application Note, Interfacing to High Speed ADCs via SPI

• AN-835 Application Note, Understanding ADC Testing and Evaluation

Warning

All the products described on this page include ESD (electrostatic discharge) sensitive devices. Electrostatic charges as high as 4000V readily accumulate on the human body or test equipment and can discharge without detection. Although the boards feature ESD protection circuitry, permanent damage may occur on devices subjected to high-energy electrostatic discharges. Therefore, proper ESD precautions are recommended to avoid performance degradation or loss of functionality. This includes removing static charge on external equipment, cables, or antennas before connecting to the device.

Help and support

For questions and more information, please visit the EngineerZone technical support community.
